Features:

*Hubbell CS6375 50 Amp Flanged Inlet

*Hubbell CS6369 50 Amp Outlet

*Courtesy Edison w/USB A & C Charge Ports (5 Amp Dedicated Breaker)

*Volt / Amp Meter Over Each Leg

*6 Circuits:  (5) 20amp (1) 30 Amp

*6 Edison Outlets

*1 Neutrik True1 Outlet

*1 Hubbell L5-30 Outlet

*3U Chassis

Description:

The D 2/5.2 50 Amp distro built by LM Tour Systems is intended for audio visual productions. The distro features a 50 amp “Cali” inlet and outlet. The inlet and outlet are wired together pre-breaker for linked applications. 2 hot legs are denotated as “X” and “Y”. Indicator lights are located by the power inlet to show when voltage is present on the input side for troubleshooting. Separate meters showing voltage and amperage draw are provided for each leg. A front mounted courtesy outlet is provided and features a dedicated 5-amp breaker and USB A & C charge ports. 6 front mounted breakers are provided. Each breaker is numbered 1-6 and corresponds to an outlet(s). The breakers also note the hot leg (X or Y) below them. The rear panel features 6 Edison outlets, a True1 outlet and a L5-30 twist lock outlet. 4 of the Edison outlets are dedicated 20-amp circuits. Circuit 6 handles the front mounted courtesy outlet, 2 rear duplex outlets and the True1 outlet. A dedicated L5-30 twist lock outlet is provided for higher drawing items such as power amps.

The front panel is built from .125” black anodized brushed aluminum. The chassis is built from .063” black anodized aluminum.
