Features:

*1 True1 Inlet

*10 True1 Outlets

*20 Amp Hydraulic Breaker

*Volt/Amp Meter

*1RU Chassis

Description:

The LM Tour Systems 26-0268 TRUE1 Power Distribution Box provides ten powerCON TRUE1 outputs in a compact 1U rack-mount enclosure. Designed for touring audio, video and production systems, it offers a consistent power connection format for equipment traveling between North American and international power environments.

A single powerCON TRUE1 inlet feeds ten powerCON TRUE1 outlets positioned across the front and rear panels. This layout allows equipment mounted inside the rack to remain connected at the rear while providing convenient front-panel connections for temporary or external devices.

An integrated digital meter displays the incoming voltage and system current draw. Because the voltage meter is connected on the line side of the breaker, users can verify the supplied voltage before energizing the connected equipment. A 20-amp circuit breaker provides system control and overcurrent protection.

The internal assembly uses heavy-duty 12 AWG wiring, secure power distribution connections and a dedicated chassis-ground connection. Each unit is hand-wired, assembled and individually tested by LM Tour Systems.

This distribution box is intended for use with compatible 120V or 230–240V single-phase systems and equipment designed to operate at the supplied voltage. It does not transform, regulate or automatically select voltage—the incoming voltage is passed directly to every output.
